wx-charts

微信小程序图表工具，charts for WeChat small app

基于canvas绘制，体积小巧

持续优化更新中，请保持关注~ 有任何问题欢迎在Issues中讨论

支持图表类型

• 饼图pie
• 圆环图ring
• 线图line
• 柱状图column
• 区域图area

更新记录

• 动画性能优化
• add animation 2016-12-05
• build withrollup2016-12-02
• add legend 2016-11-29

如何使用

1、直接引用编译好的文件dist/charts.js

2、自行编译

git clone https://github.com/xiaolin3303/wx-charts.git
 npm install rollup -g
 npm install
 rollup -c 或者 rollup --config rollup.config.prod.js

参数说明

optsObject

opts.canvasIdString required 微信小程序canvas-id

opts.widthNumber required canvas宽度，单位为px

opts.heightNumber required canvas高度，单位为px

opts.animationBoolean defaulttrue是否动画展示

opts.typeString required 图表类型，可选值为pie,line,column,area,ring

opts.categoriesArray required (饼图不需要) 数据类别分类

opts.dataLabelBoolean defaulttrue是否在图表中显示数据内容值

opts.yAxisObject Y轴配置

opts.yAxis.formatFunction 自定义Y轴文案显示

opts.yAxis.minNumber Y轴起始值

opts.yAxis.titleString Y轴title

opts.seriesArray required 数据列表

数据列表每项结构定义

dataItemObject

dataItem.dataArray required (饼图为Number) 数据

dataItem.colorString 例如#7cb5ec不传入则使用系统默认配色方案

dataItem.nameString 数据名称

dateItem.formatFunction 自定义显示数据内容

Example

pie chart

var Charts = require('charts.js');
 new Charts({
     canvasId: 'pieCanvas',
     type: 'pie',
     series: [{
         name: '成交量1',
         data: 15,
     }, {
         name: '成交量2',
         data: 35,
     }, {
         name: '成交量3',
         data: 78,
     }, {
         name: '成交量4',
         data: 63,
     }],
     width: 320,
     height: 200,
     dataLabel: false
 });

ring chart

new Charts({
     canvasId: 'pieCanvas',
     type: 'ring',
     series: [{
         name: '成交量1',
         data: 15,
     }, {
         name: '成交量2',
         data: 35,
     }, {
         name: '成交量3',
         data: 78,
     }, {
         name: '成交量4',
         data: 63,
     }],
     width: 320,
     height: 200,
     dataLabel: false
 });

line chart

new Charts({
     canvasId: 'lineCanvas',
     type: 'line',
     categories: ['2012', '2013', '2014', '2015', '2016', '2017'],
     series: [{
         name: '成交量1',
         data: [0.15, 0.2, 0.45, 0.37, 0.4, 0.8],
         format: function (val) {
             return val.toFixed(2) + '万';
         }
     }, {
         name: '成交量2',
         data: [0.30, 0.37, 0.65, 0.78, 0.69, 0.94],
         format: function (val) {
             return val.toFixed(2) + '万';
         }
     }],
     yAxis: {
         title: '成交金额 (万元)',
         format: function (val) {
             return val.toFixed(2);
         },
         min: 0
     },
     width: 320,
     height: 200
 });

columnChart

new Charts({
     canvasId: 'columnCanvas',
     type: 'column',
     categories: ['2012', '2013', '2014', '2015', '2016', '2017'],
     series: [{
         name: '成交量1',
         data: [15, 20, 45, 37, 4, 80]
     }, {
         name: '成交量2',
         data: [70, 40, 65, 100, 34, 18]
     }],
     yAxis: {
         format: function (val) {
             return val + '万';
         }
     },
     width: 320,
     height: 200
 });

areaChart

new Charts({
     canvasId: 'areaCanvas',
     type: 'area',
     categories: ['2016-08', '2016-09', '2016-10', '2016-11', '2016-12', '2017'],
     series: [{
         name: '成交量1',
         data: [70, 40, 65, 100, 34, 18],
         format: function (val) {
             return val.toFixed(2) + '万';
         }
     }, {
         name: '成交量2',
         data: [15, 20, 45, 37, 4, 80],
         format: function (val) {
             return val.toFixed(2) + '万';
         }
     }],
     yAxis: {
         format: function (val) {
             return val + '万';
         }
     },
     width: 320,
     height: 200
 });

测试

1. iPhone 6s, IOS 9.3.5
2. 小米4, ANDORID 6.0.1
